Aluminium doors
PE78N
Lightness, durability and modern design are the features of the HENSFORT PE78N aluminum system, which are particularly valued by investors not only in business, but more and more often in single-family houses and modern passive houses.
Shaping system with three-chamber profile structures with a fitting groove used in windows and balcony doors made of PVC profiles. The structural depth of sections for frames is 78 mm, and for sashes - 86 mm. The use of multi-chamber 42 mm thermal separators and a two-component central seal allows high thermal insulation. The system allows the installation of glass fillings (single and composite glazing) or non-transparent panels with a thickness of 17-61 mm. In the PE78N version, the frame heat transfer coefficient is from 1.7 W / (m² · K). In the warmer version PE78N HI with the lock of the under-glass chamber and insulating insert Uf is from 0.9 W / (m² · K).
ALUMINIUM SHAPES
- EN AW-6060 per PN-EN 573-3 status T66 per PN-EN 515 Al Mg Si 0.5 F22 in line with DIN 1725 T1, DIN 17615T1
THERMAL PERFORMANCE
- Frame heat transfer coefficient, Uf from 1.1 W/(m2.K)
INFILLS
- Single glazing or glazing unit with any type of glass or opaque panel, from 23 to 61 mm thick
SURFACE FINISH
- Powder coated with PE paints in line with the Qualicoat requirements, all RAL palette colours available.
- Anodised version in the following colours: natural aluminium, olive, champagne, gold, “old gold”, brown – as per the Qualanod requirements.
- Lacquered to “wood” colour
SEALING
- EPDM synthetic rubber in line with the 7863 standard and implementation of the standard in line with ISO 3302-01, E2
FITTINGS
- We install only fittings made by reputable companies, such as: Sobinco, Savio, Winkhaus, Siegenia, etc.
APPROVALS AND QUALITY CERTIFICATES
- Initial type testing per PN-EN 14351-1, burglar protection class certificate RC2 per PN-EN 1627-2011, RC3 per PN-EN 1627-2012
STANDARD EQUIPMENT
- Siegenia Titan AF fittings
- Mishandling device
- One security striker plate
- Sash lift
- Standard auminium handle
- Double glazing Ug=0,5 W/(m2.K)
